DAF CF65, CF75, CF85 Series . Manual - part 1165

©

 200423

4-1

Removal and installation

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ75 series

5

4. REMOVAL AND INSTALLATION

4.1 REMOVAL AND INSTALLATION, INTERIOR FILTER ELEMENT

Removing interior filter
1.

Open the grille.

2.

Push the locknut on the filter casing to one

side and remove the filter element.

Fitting interior filter
1.

Fit the filter element.

2.

Push the filter element into the locknut on the

filter casing.

3.

Close the grille.

Engine, cooling system and fuel system

K1 01 033

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

4-2

©

 200423

Removal and installation

5

ΧΦ75 series

4.2 REMOVAL AND INSTALLATION, AIR FILTER ELEMENT

Removing the air filter element
1.

Loosen all the clamping brackets (1) of the

air filter cover (2).

2.

Remove the air filter cover (2).

3.

Remove the air filter element (3).

4.

Clean the inside of the air filter housing and

the air filter cover.

5.

When replacing the air filter element, reset

the air filter indicator, if fitted, by pressing the

button on the indicator.

i400443

1

5

2

4

3

i400869

©

 200423

4-3

Removal and installation

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΧΦ75 series

5

Installing the air filter element
1.

Fit the air filter element (3) in the air filter

housing.

2.

Fit the air filter cover. Note the arrow (4) on

the air filter cover (2).

3.

Fit all the clamping brackets (1).

4.

Check that the flexible sealing bellows (5) on

the air intake is not damaged. Replace if

necessary.

i400443

1

5

2

4

3

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

4-4

©

 200423

Removal and installation

5

ΧΦ75 series

4.3 REMOVAL AND INSTALLATION, COOLANT FILTER

When the coolant is hot, there is an

overpressure in the cooling system.

Carefully remove the filler cap to

release the overpressure.

Do not remove the filler cap when the

engine is running.

Coolant is a toxic fluid. Contact with

the skin should therefore be

avoided.

In the event of contact with the skin:

remove the liquid with paper or a

cloth, wash with soap and water. If

irritation persists, consult a doctor.

If swallowed: DO NOT induce

vomiting. Rinse mouth, drink two

glasses of water and consult a

doctor.

In the event of inhalation: get fresh

air and rest.

In order to avoid damaging the

cylinder block, do not top up a warm

engine with coolant.

Removing the coolant filter
1.

Place a tray beneath the coolant filter to

collect any escaping coolant.

2.

Remove the filler cap from the expansion

tank.

3.

Turn the shut-off valve (1) clockwise to the

"C" position.

4.

Remove the coolant filter by turning it

counter-clockwise.

Installing the coolant filter
1.

Clean the sealing face of the coolant filter.

2.

Apply a small amount of coolant to the

sealing ring of the coolant filter.

3.

Fit the coolant filter so that the sealing ring

makes contact. Then tighten the filter by

hand

∂ to • of a turn.

4.

Turn shut-off valve (1) anti-clockwise to the

"O" position.

5.

Fit the filler cap on the expansion tank.

6.

Run the engine and check that the coolant

filter seals correctly.

7.

Check the coolant level.

}

O

1

C

M200372
