DAF CF65, CF75, CF85 Series . Manual - part 1077

©

 200448

2-5

Stabilisers, torque rods and leaf suspension

TECHNICAL DATA

ΧΦ65/75/85 series

9

0

Leading rear axle, vehicle in FTP version

(1) Evenly tighten the two U-bolt nuts alternately.

A

Attachment bolt M20 for shock absorber,

property class 8.8

250

≥ 25 Nm

B

Attachment nut M12 for bellows

30 Nm

C

U-bolt nut M20, property class 10.9

553 Nm

(1)

D

Attachment nut M10 for bellows

30 Nm

E

Attachment bolt M16 for leaf spring,

property class 10.9

100 Nm

F

Attachment bolt/nut M20 for leaf spring,

property class 10.9/10

553 Nm

G

Attachment bolt/nut M24 for leaf spring

830 Nm

H

Attachment bolt/nut M16 for spring

bracket, property class 10.9

310 Nm

I

Attachment bolt/nut M10 for bellows

support, property class 10.9/10

60

≥ 4 Nm

A

D

E

F

E

A

G

B

H

B

I

D

C

C9 00 481

TECHNICAL DATA

2-6

©

 200448

Stabilisers, torque rods and leaf suspension

0

ΧΦ65/75/85 series

9

Double front axle

(1) Evenly tighten the two U-bolt nuts alternately.

(2) Fit new self-locking nut.

(3) Tighten until the split pin fits (max. 60

).

It is not allowed to fit a self-locking nut to the ball

end with split pin hole.

A

Attachment bolt M24 for spring assembly,

property class 10.9

880 Nm

B

U-bolt nut
-

if flange nut M20, with yellow washer

450

≥ 40 Nm

(1)

-

if yellow zinc-plated hexagonal nut

M20, property class 10, with black

washer

400

≥ 40 Nm

(1)

C

Self-locking nut M16

65 Nm

D

Ball end nut
-

if self-locking nut

285 Nm

(2)

-

if castle nut

285 Nm

(3)

E

Attachment bolt/nut M12 for stabiliser rod

bearing bush cover, property class 10.9/10

110

≥ 8 Nm

F

Attachment bolt/nut M16 for stabiliser rod

shackle, property class 10.9/10

260

≥ 20 Nm

C900465

B

E

F

E

F

A

B C

A

D

D

A

C

C

F

F

C

A

©

 200448

2-7

Stabilisers, torque rods and leaf suspension

TECHNICAL DATA

ΧΦ65/75/85 series

9

0

Rear axle, leaf suspension

(1) Evenly tighten the two U-bolt nuts alternately.

A

Attachment bolt/nut M16 for spring

bracket, property class 10.9/10

260

≥ 20 Nm

B

Attachment bolt M24 for spring assembly,

property class 10.9

880 Nm

C

U-bolt nut
-

if flange nut M24, with black washer

750

≥ 50 Nm

(1)

-

if yellow zinc-plated hexagonal nut

M24, property class 10, with black

washer

615

≥ 50 Nm

(1)

D

Self-locking nut M16 for shock absorber

65 Nm

E

Catch bolt M12, property class 10.9

68

≥ 12 Nm

F

Attachment bolt/nut M14 for stabiliser rod

bracket, property class 10.9/10

170

≥ 15 Nm

D

A

A

B

C

D

F

C9 00 478

B

E

A

A

TECHNICAL DATA

2-8

©

 200448

Stabilisers, torque rods and leaf suspension

0

ΧΦ65/75/85 series

9

Rear axle, air-sprung

(1) Bellows must first be tightened on the chassis side.

(2) The high hexagonal nut can be recognised by the nut height, which is 1.5 x thread

. Evenly tighten the two U-bolt nuts

alternately.

(3) The yellow zinc-plated hexagonal nut can be recognised by the nut height, which is 1 x thread

. Evenly tighten the two U-bolt

nuts alternately.

A

Attachment nut M10 for bellows, property

class 10

46 Nm

(1)

B

Attachment bolt M16 for bellows, property

class 8.8

195 Nm

(1)

C

Attachment bolt M20 for shock absorber,

property class 10.9

520

≥ 40 Nm

D

U-bolt nut
-

if black high hexagonal nut M24 with

black washer

770

≥ 60 Nm

(2)

-

if yellow zinc-plated hexagonal nut

M24, property class 10, with black

washer

615

≥ 50 Nm

(3)

E

Clamping flange bolt M18 for triangular

link, property class 12.9

460

≥ 40 Nm

F

Attachment bolt M14, for triangular link

ball, property class 10.9

135 Nm

G

Attachment bolt/nut M16 for stabiliser

shackle support, property class 10.9/10

260

≥ 20 Nm

H

Attachment bolt/nut M10 for bellows

support, property class 10.9/10

60

≥ 4 Nm

C9 00 480

A

H

H

D

C

B

B

A

E

E

F

G
