INSTALLATION (1) Place riser in position on seat. ion frame (Fig. 35). Tighten bolts to 48 N·m (35 ft. (3) Install seat into vehicle. BENCH SEAT RISER - THIRD REMOVAL (1) Remove seat track. (Refer to 23 - BODY/ SEATS/BENCH SEAT TRACK - REMOVAL) (2) Remove bolts attaching riser to seat cushion frame and remove the riser. (Fig. 40). INSTALLATION (1) Place riser in position on seat. frame (Fig. 40). Tighten nuts to 48 N·m (35 ft. lbs.) (3) Install seat track. (Refer to 23 - BODY/SEATS/ BENCH SEAT TRACK - INSTALLATION) SEAT BACK HINGE COVERS - REMOVAL (1) Remove seat from vehicle. Refer to Owner’s Manual for proper procedures. (2) Remove screws attaching upper hinge cover to seat back hinge (Fig. 36). (3) Remove upper cover from seat back hinge. back hinge. (5) Remove lower cover from hinge. INSTALLATION (1) Place lower cover in position on hinge. back hinge (Fig. 36). Tighten screws to 2.3 N·m (20 (3) Place upper cover in position on seat back hinge. (4) Install screws attaching upper hinge cover to seat back hinge. Tighten screws to 2.3 N·m (20 in. (5) Install seat in vehicle. BENCH SEAT BACK HINGE REMOVAL NOTE: Bench seats equipped with child restraint (1) Remove the bench seat back upper and lower hinge covers. (Refer to 23 - BODY/SEATS/SEAT (2) Remove the seat back. (Refer to 23 - BODY/ SEATS/BENCH SEAT BACK - REMOVAL) (3) Remove bolts attaching seat back hinge to seat cushion frame (Fig. 37). (4) Remove seat back hinge from seat. INSTALLATION INSTALLATION NOTE: Bench seats equipped with child restraint (1) Place hinge in position on seat. left side) hinge latch release arm. (3) Engage synchronizing cable housing into seat back hinge. Fig. 36 BENCH SEAT BACK HINGE COVERS - TYPICAL 1 - UPPER COVER SCREWS 23 - 100 SEATS RS BENCH SEAT RISER - SECOND ROW (Continued) |
