2. Position the A-pillar (1) flush on top of the section of the instrument panel and press it into the retain- 3. Lift the rubber lip on the A-pillar seal over the A-pil- lar trim with a plastic wedge. CARPET REMOVAL REMOVAL - CARPET (LEFT SIDE) 1. Remove the front seat. (Refer to 23 - BODY/ SEATS/SEAT - REMOVAL). 2. Remove the rear center console. (Refer to 23 - BODY/INTERIOR/CENTER CONSOLE - REMOVAL). 3. Remove the cover on center console. (Refer to 23 - BODY/INTERIOR/CENTER CONSOLE - REMOVAL). 4. Remove the ashtray housing with the stowage compartment in the front of the center console. 5. Remove the air outlet cover in the footwell. 6. Remove the door sill trim plate (4). (Refer to 23 - BODY/INTERIOR/DOOR SILL TRIM PLATE - REMOVAL). 7. Remove the kick panel (2) in the left footwell by pulling the edge guard (1) off in the area of the kick 8. Remove the pedal cover. ZH INTERIOR 23 - 379 |
