5. Remove the lower splash shield screws (1) and the shield (2). 6. Place a suitable drain pan under the crankcase drain. 7. Remove the drain plug from the crankcase and allow the oil to drain into the pan. Inspect the drain 8. Remove the oil filter. (Refer to 9 - ENGINE/LUBRI- CATION/OIL FILTER - REMOVAL). 9. Install the drain plug (1). Tighten to 30 N·m (22 ft. lbs.). 10. Install the lower splash shield. Tighten to 7 N·m (5 ft. lbs.). 11. Lower the vehicle and fill the crankcase with spec- ified type and amount of engine oil. 12. Install a new oil filter. (Refer to 9 - ENGINE/LU- BRICATION/OIL FILTER - INSTALLATION). 13. Install the oil filler cap. 14. Start the engine and inspect for leaks. 15. Turn off the engine and inspect the oil level. USED ENGINE OIL DISPOSAL Care should be exercised when disposing used engine oil after it has been drained from a vehicle engine. See the ZH ENGINE - 3.2L SERVICE INFORMATION 9 - 793 |
