Chrysler 300/300 Touring/300C, Dodge Magnum. Manual - part 528

3. Position the lamp lens (2) on the lamp base (1)

and firmly snap into place.

4. Connect the battery negative remote cable or insert

fuse in the PDC.

8L - 142

LAMPS/LIGHTING - EXTERIOR - SERVICE INFORMATION

UNDERHOOD LAMP UNIT - POLICE

REMOVAL

1. Open hood, disconnect and isolate the battery neg-

ative remote terminal or pull fuse in the PDC.

2. Disconnect the wire harness connector (1) from

lamp unit (2).

3. Remove the push-pin fastener attaching underhood

lamp unit (2) to inner hood panel.

4. Remove the underhood lamp unit (2) from the

vehicle.

INSTALLATION

1. Position the underhood lamp unit (2) on the hood

inner panel.

2. Install the push-pin fastener attaching the lamp unit

base (2) to the inner hood panel.

3. Connect the wire harness connector (1).

4. Connect the battery negative remote cable or rein-

sert fuse in the PDC.

5. Close hood.

LAMPS/LIGHTING - EXTERIOR - SERVICE INFORMATION

8L - 143

LAMPS/LIGHTING - INTERIOR - ELECTRICAL DIAGNOSTICS

TABLE OF CONTENTS

page

LAMPS/LIGHTING - INTERIOR - ELECTRICAL

DIAGNOSTICS
DIAGNOSIS AND TESTING

8L - 144

LAMPS/LIGHTING - INTERIOR - ELECTRICAL DIAGNOSTICS

DIAGNOSIS AND TESTING

LAMPS/LIGHTING - INTERIOR - ELECTRICAL DIAGNOSTICS

8L - 145
