2. To replace spark plug tube seals (2): a. Using a suitable pry tool, carefully remove tube seals (2). b. Position new seal (2) with the part number on seal facing cylinder head cover. c. Install seals using MD-998306 (1). 3. Install cylinder head cover (1) and bolts (2). Tighten to 12 N·m (105 in. lbs.). 4. Position the wiring harness (3) on the cylinder head cover. 5. Reclip the wire harness track retaining tabs into the cover. 6. Install the ground strap/resistor retaining bolt onto the cylinder head cover. 7. Install the ignition coils (2). Tighten mounting screws to 6.7 N.m (60 in. lbs.) 8. Connect the ignition coil electrical connectors (2). 9. Install upper intake manifold (Refer to 9 - ENGINE/ MANIFOLDS/INTAKE MANIFOLD - INSTALLA- TION). 10. Connect negative battery cable. 9 - 2168 ENGINE - 3.5L - SERVICE INFORMATION LX |
