5. Align J 43765-1 protector (1) so that the lip of the tool is downward. 6. Install J 43765-1 protector (1) onto the stator shaft. Fig. 238: Locating J 43765-3 Into Rear Hub Of Oil Pump Cover Assembly 7. While holding J 43765-1 protector (3) in place, turn over the oil pump cover assembly (2) and place J 43765-1 on a press.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
8. Install J 43765-3 installer (1) into the rear hub of the oil pump cover assembly (2). 9. Press on J 43765-3 installer (1) until the stator shaft seats. Fig. 239: Checking Total Indicated Runout (TIR) Of Stator Shaft 10. Check the total indicated runout (TIR) of the stator shaft as follows: 1. Install the oil pump cover assembly (1) in a lathe, clamping on dimension D. 2. Use a dial indicator, to make sure the oil pump cover surface C is square with the
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
dimension D. 3. Check the TIR along the stator shaft axis B at the stator shaft pitch diameter A. Specification: The TIR must not exceed 0.20 mm (0.008 in). 4. Remove the oil pump cover assembly from the lathe. STATOR SHAFT NEEDLE BEARING REPLACEMENT Tools Required J 26941 Oil Pump Cover Needle Bearing Remover. See Special Tools. J 8092 Universal Driver J 43775 Oil Pump Cover Needle Bearing Installer. See Special Tools. Replacement
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 240: Installing J 26941 (1) Into Bearing 1. Install J 26941 (1) into the bearing (2) so that the lips of the tool engage the bottom lip of the needle bearing race. See Special Tools. 2. Tighten the screw of J 26941 finger tight. See Special Tools. IMPORTANT: Use this procedure if replacing only the stator shaft needle bearing.
