Fig. 108: Identifying Transmission Mount Nuts 3. Lower the transmission. 4. Install the transmission mount to the transmission support retaining nut or nuts.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Tighten: Tighten the nut or nuts to 50 N.m (37 lb ft). 5. Remove the transmission jack. 6. Lower the vehicle. TRANSMISSION REPLACEMENT Tools Required J 21366 Converter Holding Strap J 44257 Connector Removal Tool Removal Procedure 1. Remove the transmission fluid level indicator. 2. Remove the starter motor. Refer to Starter Motor Replacement (4.3L) or Starter Motor Replacement (4.8L, 5.3L, 6.0L, and 6.2L) or Starter Motor Replacement (6.6L) . IMPORTANT: If replacing a failed transmission, the "FastLearn" (adapt) procedure must be performed. This can be done in one step using
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 109: View Of Torque Convertor Bolt 3. Rotate the engine clockwise, using the crankshaft bolt in order to access the torque converter bolts through the starter opening. Have an assistant rotate the engine while 4. Remove the torque converter bolts. 5. Completely raise the vehicle. 6. Drain the transmission fluid. IMPORTANT: Rotate the engine clockwise ONLY, rotating the engine counterclockwise may loosen the crankshaft balancer bolt.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 110: Range Selector Cable Heat Shield 7. Remove the range selector cable heat shield bolts. 8. Remove the range selector cable heat shield.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
|
|
