Fig. 111: Range Selector Cable
Courtesy of GENERAL MOTORS CORP.
9. Remove the range selector cable end from the transmission range selector lever stud.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 112: View Of Shift Cable Bracket And Bolts
Courtesy of GENERAL MOTORS CORP.
10. Remove the shift cable bracket bolts and bracket from the transmission.
11. Position the bracket with the cable attached out of the way.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 113: Identifying Fuel Line Retainer Bolts
Courtesy of GENERAL MOTORS CORP.
12. Remove the fuel line retainer (1) bolts on the left side of the transmission.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 114: Identifying Fuel Line Bracket
Courtesy of GENERAL MOTORS CORP.
13. Remove the fuel line bracket nut from the converter housing stud.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
