Fig. 52: View Of Steering Cable Retainer On Steering Column
Courtesy of GENERAL MOTORS CORP.
8. Install the retainer securing the cable to the steering column.
9. Position the carpet and insulation around the driver's area.
10. Install the instrument panel knee bolster. Refer to Knee Bolster Replacement (with RPO
SLT) or Knee Bolster Replacement (without RPO SLT) .
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
11. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
Fig. 53: Cable Clips & Transfer Case, If Equipped
Courtesy of GENERAL MOTORS CORP.
12. Install the cable clips (2) to the transfer case, if equipped.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 54: View Of Cable Clips At Floor Panel Reinforcement
Courtesy of GENERAL MOTORS CORP.
13. Install the cable clips to the floor panel reinforcement.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 55: Range Selector Cable
Courtesy of GENERAL MOTORS CORP.
14. Ensure the transmission manual shaft is positioned in mechanical park.
15. Install the range selector cable to the range selector cable bracket.
16. Install the retainer securing the range selector cable to the bracket.
17. Install the range selector cable end to the transmission range selector lever stud.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
