Chevrolet Silverado / GMC Sierra. Manual - part 852
Fig. 44: Cable Clips & Transfer Case, If Equipped
Courtesy of GENERAL MOTORS CORP.
10. Remove the cable clips (2) from the transfer case, if equipped.
11. Lower the vehicle.
12. Ensure that the steering column shift lever is still in the park position.
13. Pull back the carpet and insulation around the driver's area.
14. Remove the instrument panel knee bolster. Refer to Knee Bolster Replacement (with
RPO SLT) or Knee Bolster Replacement (without RPO SLT) .
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 45: View Of Steering Cable Retainer On Steering Column
Courtesy of GENERAL MOTORS CORP.
15. Remove the retainer securing the cable to the steering column.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 46: View Of Cable, Steering Column Ball Stud & Steering Column Bracket
Courtesy of GENERAL MOTORS CORP.
16. Remove the cable end from the steering column ball stud.
17. Depress the tangs and remove the cable from the steering column bracket.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 47: View Of Range Selector Cable
Courtesy of GENERAL MOTORS CORP.
18. Remove the range selector cable from the support.
IMPORTANT: Avoid unnecessary twisting/bending of the range selector
cable when removing the cable from the support.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
