Fig. 48: View Of Cable Grommet At Floor Panel
Courtesy of GENERAL MOTORS CORP.
19. Remove the cable grommet from the floor panel.
20. Remove the cable from the vehicle.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
1. Install the cable to the vehicle.
Fig. 49: View Of Cable Grommet At Floor Panel
Courtesy of GENERAL MOTORS CORP.
2. Install the cable grommet to the floor panel.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 50: View Of Range Selector Cable
Courtesy of GENERAL MOTORS CORP.
3. Install the range selector cable to the support.
4. Ensure that the transmission manual shaft lever is in the mechanical park position.
IMPORTANT: Avoid unnecessary twisting/bending of the range selector
cable when installing the cable to the support.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Fig. 51: View Of Cable, Steering Column Ball Stud & Steering Column Bracket
Courtesy of GENERAL MOTORS CORP.
5. Install the cable to the steering column bracket.
6. Ensure the tangs fully seat (snap) into the steering column bracket.
7. Install the cable end to the steering column ball stud.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
