Chevrolet Silverado / GMC Sierra. Manual - part 634
Fig. 64: View Of Right Glow Plug Harness Bracket Bolts
Courtesy of GENERAL MOTORS CORP.
25. Install the right glow plug harness bracket bolts.
Tighten: Tighten the glow plug harness bracket bolt to 10 N.m (89 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 65: View Of Left Glow Plug Harness Bracket Bolts
Courtesy of GENERAL MOTORS CORP.
26. Install the left glow plug harness bracket bolts.
Tighten: Tighten the glow plug harness bracket bolt to 10 N.m (89 lb in).
ENGINE COOLANT THERMOSTAT HOUSING INSTALLATION
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 66: View Of Thermostat Housing
Courtesy of GENERAL MOTORS CORP.
1. Install the thermostat housing.
2. Install the thermostat housing bolts and nuts.
Tighten: Tighten the thermostat housing bolts and nuts to 25 N.m (18 lb ft).
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 67: View Of Fuel Pipe Bracket Bolt
Courtesy of GENERAL MOTORS CORP.
3. Install the fuel pipe bracket bolt.
Tighten: Tighten the fuel pipe bracket bolt to 25 N.m (18 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
