Fig. 21: View Of Left Fuel Rail At Pump Pipe
Courtesy of GENERAL MOTORS CORP.
9. Install the left fuel rail to pump pipe.
Tighten: Tighten the fuel rail to pump pipe nut to 41 N.m (30 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 22: View Of Coolant Pipe
Courtesy of GENERAL MOTORS CORP.
10. Install the coolant pipe.
11. Install the coolant pipe bolt and nut.
Tighten: Tighten the coolant pipe bolt and nut to 25 N.m (18 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 23: View Of Distribution Block, Fuel Line Assembly & Bolts
Courtesy of GENERAL MOTORS CORP.
12. Install the distribution block and fuel line assembly.
13. Install the distribution block and fuel line assembly bolts.
Tighten: Tighten the fuel line assembly bolts to 25 N.m (18 lb ft).
