Fig. 182: View Of Left Exhaust Pipe Heat Shield & Bolts
Courtesy of GENERAL MOTORS CORP.
38. Install the heat shield.
39. Install the left exhaust pipe heat shield bolts.
Tighten: Tighten the bolts to 8 N.m (71 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 183: View Of Fill Tube To Bellhousing Nuts
Courtesy of GENERAL MOTORS CORP.
40. If equipped with an automatic transmission, position the fill tube to the studs.
41. Install the transmission fill tube to bellhousing nuts.
Tighten: Tighten the nuts to 18 N.m (13 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 184: View Of Turbocharger Exhaust Pipe & Clamp
Courtesy of GENERAL MOTORS CORP.
42. Slide the clamp onto the exhaust pipe. Tighten the exhaust pipe clamp.
Tighten: Tighten the clamp to 40 N.m (30 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
43. Install the left and right wheelhouse liners. Refer to Front Wheelhouse Liner
Replacement - Right Side (GMC) or Front Wheelhouse Liner Replacement - Right
Side (Chevrolet) and Front Wheelhouse Liner Replacement - Left Side (Chevrolet) or
Front Wheelhouse Liner Replacement - Left Side (GMC) .
44. Install the transmission. Refer to Transmission Replacement .
45. If a NEW turbocharger was installed, perform the turbocharger learn procedure. Refer to
Turbocharger Learn .
46. Road test the vehicle for normal operation.
47. Inspect for coolant, oil, or exhaust leaks. Correct as necessary.
TURBOCHARGER OIL FEED PIPE REPLACEMENT
Removal Procedure
