Fig. 45: Identifying Engine Shield And Retaining Bolts
Courtesy of GENERAL MOTORS CORP.
11. Install the engine protection shield and bolts.
Tighten: Tighten the engine protection shield bolts to 20 N.m (15 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 46: Identifying Oil Pan Skid Plate
Courtesy of GENERAL MOTORS CORP.
12. Install the oil pan skid plate.
Tighten: Tighten the bolts to 20 N.m (15 lb ft).
13. Install the right front tire and wheel. Refer to Tire and Wheel Removal and Installation .
14. Install the front fender wheelhouse inner panel.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
15. Install the starter motor. Refer to Starter Motor Replacement (6.6L) .
16. Lower the vehicle.
POSITIVE CRANKCASE VENTILATION VALVE REPLACEMENT (DRIVER SIDE)
Removal Procedure
Fig. 47: View Of Turbocharger Clamp & Charged Air Cooler Inlet Duct Connector
Courtesy of GENERAL MOTORS CORP.
IMPORTANT: After removing the charged air cooler duct, cover the
turbocharger opening with tape in order to prevent entry of
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
1. Loosen the charged air cooler inlet duct connector to turbocharger clamp (1).
2. Remove the charged air cooler inlet duct connector (4) from the turbocharger.
objects.
IMPORTANT: Do not use a screwdriver or other tool to pry the hose loose.
The hose can be torn or damaged. Loosen the hose by
twisting.
