3. If 4-wheel drive (4WD) vehicle, raise the vehicle in order to remove the front tires and
wheels and support with jackstands.
4. Remove the right front tire and wheel, if necessary. Refer to Tire and Wheel Removal
and Installation .
5. Remove the pushpins holding the right front fender wheelhouse inner panel (1).
6. Remove the wheelhouse inner panel.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 34: View Of Engine Mount To Engine Mount Frame Bracket Bolt (Right)
Courtesy of GENERAL MOTORS CORP.
7. Working through the wheelhouse opening remove the 3 bolts retaining the engine mount to
NOTE:
Refer to ENGINE MOUNTING NOTICE
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
the engine mount frame bracket.
Fig. 35: Identifying Oil Pan Skid Plate
Courtesy of GENERAL MOTORS CORP.
8. Remove the oil pan skid plate, if equipped.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 36: Identifying Engine Shield And Retaining Bolts
Courtesy of GENERAL MOTORS CORP.
9. Remove the engine protection shield from the vehicle, if equipped.
