Fig. 290: View Of Oil Pan Drain Plug
Courtesy of GENERAL MOTORS CORP.
1. Open the hood.
2. Remove the oil fill cap.
3. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle .
4. Place a oil drain pan under the oil pan drain plug.
5. Remove the oil pan drain plug.
6. Drain the engine oil.
7. Wipe the excess oil from the drain plug hole and plug.
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
Fig. 291: View Of Engine Oil Filter
Courtesy of GENERAL MOTORS CORP.
IMPORTANT: Check the old oil filter to ensure that the filter seal is not left
on the engine block.
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
8. Remove the oil filter from the engine block.
9. Wipe the excess oil from the oil filter mounting.
Installation Procedure
Fig. 292: View Of Engine Oil Filter
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
Courtesy of GENERAL MOTORS CORP.
1. Lubricate the oil filter seal with clean engine oil.
2. Install the oil filter to the engine block.
Tighten: Tighten the oil filter to 30 N.m (22 lb ft).
Fig. 293: View Of Oil Pan Drain Plug
Courtesy of GENERAL MOTORS CORP.
3. Install the oil drain plug to the engine block.
Tighten: Tighten the oil pan drain plug to 25 N.m (18 lb ft).
4. Lower the vehicle.
NOTE:
Refer to Fastener Notice .
