Fig. 99: Cleaning Window 23. Clean any excess urethane adhesive from the body.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 100: Performing Water Hose Test 24. Use a soft spray of warm water in order to immediately water test the window. 25. Inspect the window for leaks. 26. If any leaks are found, use a plastic paddle in order to apply extra urethane adhesive at the leak point. 27. Retest the window for leaks. IMPORTANT: Do not direct a hard stream of high pressure water to the freshly applied urethane adhesive. CAUTION: Insufficient curing of urethane adhesive may allow unrestrained occupants to be ejected from the vehicle For the moisture-curing type of urethane adhesive,
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
28. Maintain the following conditions in order to properly cure the urethane adhesive: Partially lower a door window in order to prevent pressure buildups when closing Do not drive the vehicle until the urethane adhesive is cured. Refer to the above curing Do not use compressed air in order to dry the urethane adhesive. 29. Complete the window installation. ADHESIVE INSTALLATION OF STATIONARY WINDOWS (REAR WINDOW) at least 24 hours for the complete curing of the For the chemical-curing type of urethane adhesive,
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 101: Applying Pinch-Weld Primer 1. Remove all mounds or loose pieces of urethane adhesive from the pinch-weld area. 2. If the original window is being reused, remove all but a thin film of the existing urethane adhesive from the window surface by using a clean utility knife or razor blade scraper. 3. Inspect the following components for the causes of a broken window: The flange of the window opening CAUTION: Refer to GLASS AND SHEET METAL HANDLING CAUTION . IMPORTANT: Remove all but approximately 2 mm (3/64 in) of the existing bead of urethane adhesive from the pinch-weld flange.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
