Fig. 95: View Of Modified Applicator Nozzle
Courtesy of GENERAL MOTORS CORP.
18. Cut the applicator nozzle in order to provide a bead of 8 mm (0.316 in) wide and 12.7 mm
(1/2 in) high.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 96: Applying Bead Of Urethane Adhesive
Courtesy of GENERAL MOTORS CORP.
19. Use a cartridge-type caulking gun in order to apply a smooth, continuous bead of urethane
adhesive.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 97: Aligning Tape Lines On Window To Body
Courtesy of GENERAL MOTORS CORP.
20. Align the masking tape (1) lines on the window (2) and the body.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 98: Pressing Window Into Place
Courtesy of GENERAL MOTORS CORP.
21. Press the window firmly into place.
22. Tape the window to the body in order to minimize movement until the urethane adhesive
cures.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
