10. With the aid of an assistant, dry fit the window (1) to the opening in order to determine the
correct position.
Fig. 91: Aligning Tape Lines On Window To Body
Courtesy of GENERAL MOTORS CORP.
11. Use masking tape in order to mark the locations (1) of the window (2) in the opening.
12. Cut the masking tape in the center and remove the window from the opening.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 92: Applying Glass Prep
Courtesy of GENERAL MOTORS CORP.
13. Use a new dauber in order to apply glass prep clear #1 to the area approximately 10-16 mm
(3/8-5/8 in) around the entire perimeter of the window inner surface.
Immediately wipe the glass primed area using a clean, lint-free cloth.
IMPORTANT: Use care when applying glass prep clear #1 on the window.
This primer dries almost instantly, and may stain the viewing
area of the window if not applied evenly.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 93: Applying Glass Prep
Courtesy of GENERAL MOTORS CORP.
14. Apply a second coat of the glass prep clear #1 to the same area of the glass.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 94: Applying Glass Primer
Courtesy of GENERAL MOTORS CORP.
15. Shake the glass primer black #2 for at least 1 minute.
16. Use a new dauber in order to apply the glass primer black #2 to the same areas (2) that glass
prep clear #1 was applied.
17. Allow the glass primer to dry for approximately 10 minutes.
IMPORTANT: The glass primer black #2 is effective up to 8 hours after
applying it to the glass. The primed surface of the glass must
be kept clean.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
