Chevrolet Silverado / GMC Sierra. Manual - part 2984
Fig. 61: View Of Regulator & Screw
Courtesy of GENERAL MOTORS CORP.
2. Cycle the rear sliding window to the fully closed position.
3. Remove the screw (1) from the rear sliding window regulator and cables (2).
4. Pull forward on the regulator and cables (2) to release it from the motor/module.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 62: View Of Sliding Window Motor Module & Components
Courtesy of GENERAL MOTORS CORP.
5. Remove the rear sliding window motor/module nuts (2).
6. Disconnect the rear sliding window electrical connectors from the motor/module and relays
(1).
7. Remove the rear sliding window motor/module assembly from the vehicle.
Installation Procedure
1. Install the rear sliding window motor/module assembly to the vehicle.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 63: View Of Sliding Window Motor Module & Components
Courtesy of GENERAL MOTORS CORP.
2. Connect the rear sliding window electrical connectors to the motor/module and relays (1).
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 64: View Of Regulator & Screw
Courtesy of GENERAL MOTORS CORP.
3. Install the rear sliding window motor/module nuts (2).
Tighten: Tighten nut to 10 N.m (89 lb in).
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
