4. Install the rear sliding window regulator and cables (2) to the motor/module. 5. Install the bolt (1) to the rear sliding window regulator and cables (2). Tighten: Tighten bolt to 11 N.m (97 lb in). 6. Install the rear sliding window lower garnish molding. Refer to Rear Window Lower Garnish Molding Replacement (Regular Cab) or Rear Window Lower Garnish 7. Inspect the rear sliding window for proper operation. DOOR WINDOW REGULATOR HANDLE REPLACEMENT Fig. 65: View Of Side Door Window Regulator Handle Assembly & Retainer Clip
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
STATIONARY WINDOW REVEAL MOLDING REPAIR Removal Procedure Fig. 66: Identifying Reveal Molding Callout Component Name 1 Side Door Window Regulator Handle Retainer Clip 2 Side Door Window Regulator Handle Assembly
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
1. Lift up on the loose area of the reveal molding. 2. Clean the top edge of the window surface and the reveal molding with a 50/50 mixture of isopropyl alcohol and water by volume on a dampened lint-free cloth. Installation Procedure 1. Verify all primers and urethane adhesive are within expiration dates. Fig. 67: Applying Glass Prep CAUTION: Refer to GLASS AND SHEET METAL HANDLING CAUTION . IMPORTANT: The window reveal molding fills the cavity between the body and window. If the reveal molding is stretched or damaged, it CAUTION: Refer to Window Retention Caution .
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
2. Use a new dauber in order to apply glass prep, clear #1, to the channel area approximately 13 mm (1/2 in) to the upper edge of the window. 3. Wipe the glass primed area immediately with a clean lint-free cloth. 4. Shake the glass primer, black #2, for at least 1 minute. 5. Use a new dauber in order to apply glass primer, black #2, to the top edge of the window. IMPORTANT: Use care when applying the prep, clear #1, to the window. This primer dries almost instantly, and may stain the viewing
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
