Chevrolet Silverado / GMC Sierra. Manual - part 2982
Tighten: Tighten nuts to 5 N.m (44 lb in).
Fig. 54: View Of Pulley, Tabs & Frame
Courtesy of GENERAL MOTORS CORP.
5. Install the rear sliding window pulley (1).
1. Align the tabs (2) on the pulley (1) with the notch in the frame (3).
2. Turn the pulley downward, locking the pulley into the frame (3).
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 55: View Of Regulator Cables & Retainers
Courtesy of GENERAL MOTORS CORP.
6. Install the regulator cables (2) to the retainers (1) across the bottom edge of the window
frame.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 56: View Of Rear Window Pulley, Tabs & Cover
Courtesy of GENERAL MOTORS CORP.
7. Install the rear sliding window pulley covers (2) to the pulley (3), clip the tabs (1) in place.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 57: View Of Rear Sliding Window Stops
Courtesy of GENERAL MOTORS CORP.
8. Install the rear sliding window stops (1) in place and fully seated.
9. Cycle the rear sliding window to the fully closed position.
10. Install the lower garnish molding. Refer to Rear Window Lower Garnish Molding
Replacement (Regular Cab) or Rear Window Lower Garnish Molding Replacement
(Ext Cab/Crew Cab w/A48) or Rear Window Lower Garnish Molding Replacement
(Ext Cab/Crew Cab w/o A48) .
11. Inspect the rear sliding window for proper operation.
12. Clean the window.
REAR WINDOW WEATHERSTRIP REPLACEMENT
Removal Procedure
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
