Chevrolet Silverado / GMC Sierra. Manual - part 2980
Fig. 46: View Of Regulator Cables & Retainers
Courtesy of GENERAL MOTORS CORP.
5. Remove the regulator cables (2) from the retainers (1) located across the bottom edge of the
window frame.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 47: View Of Regulator & Screw
Courtesy of GENERAL MOTORS CORP.
6. Remove the screw (1) from regulator (2).
7. Remove the regulator (2) from the motor/module.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 48: View Of Pulley, Tabs & Frame
Courtesy of GENERAL MOTORS CORP.
8. Remove the pulley (1) from the frame.
1. Lift the end of the tabs (2) out of the window frame (3).
2. Turn upward to release the pulley (1) from the frame (3).
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 49: View Of Cable Ends At Window Guide
Courtesy of GENERAL MOTORS CORP.
9. Remove the cable ends (1) from the window guide (2) at each end of the window.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
