Fig. 34: View Of Regulator & Cables 10. Remove the regulator (1) and cables (2) from the vehicle.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 35: View Of Rear Side Window Catch Screws, Gasket, Nuts & Frame 11. Remove the rear sliding window catch screws (1), catch, gasket (2) and nuts (3). 12. Slide the window all the way to the left (driver side). 13. Release the window from the upper frame, by push downward on the window. 14. Remove the rear sliding window (4) from the frame. Installation Procedure
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 36: View Of Rear Side Window Catch Screws, Gasket, Nuts & Frame 1. Install the rear sliding window (4) to the frame. 2. Align the window to the upper and lower frame, push down the window and then pull upward locking the window in the frame. 3. Slide the window all the way to the right (passenger side). 4. Install the rear sliding window catch screws (1), catch, gasket (2) and nuts (3). NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Tighten: Tighten the nuts to 3 N.m (27 lb in). Fig. 37: View Of Regulator & Cables 5. Slide window by hand, back and forth in the window frame to ensure proper operation before installing the regulator to the motor. 6. Install the window to the halfway position. 7. Install the regulator (1) and cables (2) to vehicle.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
