Chevrolet Silverado / GMC Sierra. Manual - part 2975
6. This will allow the urethane adhesive to be separated from the window.
Leave a base of urethane on the pinchweld flange.
The only suitable lubrication is clear water.
Use J 24402-A , J 39040 or equivalent in order to remove the window. See Special
Tools.
7. Open the window, if equipped.
Fig. 27: View Of Rear Window (Pickup)
Courtesy of GENERAL MOTORS CORP.
IMPORTANT: Keep the cutting edge of the tool against the window.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
8. With the aid of an assistant, remove the window from the opening.
Installation Procedure
1. Install a stationary window into the opening. Refer to Adhesive Installation of Stationary
Windows (Windshield) or Adhesive Installation of Stationary Windows (Rear
Window).
2. Install the rear sliding window regulator, if equipped. Refer to Rear Sliding Window
Regulator Replacement.
3. Install the window lower garnish molding. Refer to Rear Window Lower Garnish
Molding Replacement (Regular Cab) or Rear Window Lower Garnish Molding
Replacement (Ext Cab/Crew Cab w/A48) or Rear Window Lower Garnish Molding
Replacement (Ext Cab/Crew Cab w/o A48) .
4. Install both rear seat headrests (extended cab). Refer to Head Restraint Replacement .
5. Raise the rear seat back.
6. Remove the double layer of masking tape around the perimeter of the painted surfaces and
interior trim.
REAR SLIDING WINDOW REPLACEMENT
Removal Procedure
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 28: View Of Rear Sliding Window Stops
Courtesy of GENERAL MOTORS CORP.
1. Cycle the rear sliding window to the halfway position.
2. Remove the rear lower garnish molding. Refer to Rear Window Lower Garnish Molding
Replacement (Regular Cab) or Rear Window Lower Garnish Molding Replacement
(Ext Cab/Crew Cab w/A48) or Rear Window Lower Garnish Molding Replacement
(Ext Cab/Crew Cab w/o A48) .
IMPORTANT: The new rear sliding window regulator and cables are
serviced as an assembly.
IMPORTANT: Use a suitable tool to lift upward on the rear sliding window
stops (1) to remove.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
3. Remove the rear sliding window stops (1).
Fig. 29: View Of Rear Sliding Window Pulley Covers
Courtesy of GENERAL MOTORS CORP.
4. Remove the rear sliding window pulley covers (2).
IMPORTANT: Use a suitable tool to release the tabs (1) from the rear
sliding window pulley (3).
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
