Fig. 24: Hinged Body Side Window
Courtesy of GENERAL MOTORS CORP.
1. Place tape from body side to window to hold in place.
2. Remove the side access door trim panel. Refer to Rear Side Access Door Trim Panel
Replacement .
3. Disconnect the window latch.
4. Remove the bolts from the hinges.
5. Remove the tape and window from the vehicle.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 25: Hinged Body Side Window
Courtesy of GENERAL MOTORS CORP.
1. Position the window and tape into position.
2. Install the bolts to the hinges.
Tighten: Tighten the bolts to 10 N.m (89 lb in).
3. Install the window latch.
4. Remove the tape and inspect the window.
5. Install the side access door trim panel. Refer to Rear Side Access Door Trim Panel
Replacement .
REAR WINDOW REPLACEMENT
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Tools Required
J 24402-A Cold Knife Glass Sealant Remover. See Special Tools.
J 39040 Quarter Window Remover. See Special Tools.
Urethane Adhesive Kit GM P/N 12346392 or Equivalent
Isopropyl Alcohol or Equivalent
Cartridge-type Caulking Gun
Commercial-type Utility Knife
Razor Blade Scraper
Suction Cups
Plastic Paddle
Removal Procedure
1. Remove the window lower garnish molding. Refer to Rear Window Lower Garnish
Molding Replacement (Regular Cab) or Rear Window Lower Garnish Molding
Replacement (Ext Cab/Crew Cab w/A48) or Rear Window Lower Garnish Molding
Replacement (Ext Cab/Crew Cab w/o A48) .
2. Remove both rear seat headrests (extended cab). Refer to Head Restraint Replacement .
3. Lower rear seat back.
4. Remove the rear sliding window regulator, if equipped. Refer to Rear Sliding Window
Regulator Replacement.
5. Cover to protect the following parts from broken glass:
1. Upper dash pad
CAUTION: If a window is cracked but still intact, crisscross the
window with masking tape in order to reduce the risk of
damage or personal injury.
IMPORTANT: Before cutting out a window, apply a double layer of masking
tape around the perimeter of the painted surfaces and
interior trim.
CAUTION: If broken glass falls into the defroster outlets, it can be
blown into the passenger compartment and cause
personal injury.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
2. Defroster outlets and A/C outlets
3. Seats and carpeting
Fig. 26: Separating Urethane Adhesive From Window
Courtesy of GENERAL MOTORS CORP.
CAUTION: When working with any type of glass or sheet metal with
exposed or rough edges, wear approved safety glasses
and gloves in order to reduce the chance of personal
injury.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
