Fig. 40: Turning Sunshade Cam Counterclockwise 4. Turn the sunshade cam (2) until it is aligned with the bracket (3) notch. 5. Install the sunshade.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 41: Sunshade Cam Locking Hole 6. Remove the suitable tool (1) from the sunshade cam locking hole (2). 7. Ensure that the sunshade cam (2) is fully seated in the bracket (3) and the sunshade slides smoothly. 8. Install the sunroof window. Refer to Sunroof Window Replacement (Extended Cab) or Sunroof Window Replacement (Crew Cab). 9. Verify the operation of the sunshade. SUNROOF SUNSHADE REPLACEMENT (CREW CAB) Removal Procedure 1. Remove the sunroof window. Refer to Sunroof Window Replacement (Extended Cab) or Sunroof Window Replacement (Crew Cab).
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 42: Sunroof Assembly Retaining Screw 2. Remove the screws (1) that retain the water trough to the sunroof assembly. 3. Remove the water trough from the sunroof assembly from the top of the vehicle.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
4. Slide the sunshade forward. Fig. 43: Track Slot, Retaining Tabs And Sunshade 5. Flex the center of the sunshade (2) upward while simultaneously sliding the panel sideways to release the retaining tabs (3) from the track slot (1). 6. Remove the sunshade from the top of the vehicle. Installation Procedure IMPORTANT: The sunshade must be removed from the top of the vehicle.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
