Fig. 44: Track Slot, Retaining Tabs And Sunshade
Courtesy of GENERAL MOTORS CORP.
1. Position the sunshade to the vehicle from the top of the vehicle.
2. Install the retaining tabs on the far side of the sunshade, starting with the center tab first in
the track slot of the sunroof.
3. Flex the center of the sunshade (2) upwards while simultaneously inserting the retaining tabs
(3) into the track slot (1).
4. Ensure that the sunshade tabs are fully seated in the track slots, and the sunshade slides
smoothly.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 45: Sunroof Assembly Retaining Screw
Courtesy of GENERAL MOTORS CORP.
5. Install the water trough to the sunroof from the top of the vehicle.
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
6. Install the screws (1) that retain the water trough to the sunroof.
Tighten: Tighten the screws to 1 N.m (9 lb in).
7. Install the sunroof window. Refer to Sunroof Window Replacement (Extended Cab) or
Sunroof Window Replacement (Crew Cab).
SUNROOF SUNSHADE STOP REPLACEMENT
Fig. 46: View Of Sunroof Sunshade Stop
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
Preliminary Procedure:
Remove the sunroof window. Refer to Sunroof Window Replacement (Extended Cab)
or Sunroof Window Replacement (Crew Cab).
1
Sunroof Window Stop Screws (Qty: 2)
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
SUNROOF SWITCH REPLACEMENT (CREW CAB)
Removal Procedure
1. Remove the overhead console in order to access the sunroof switch. Refer to Roof Console
Replacement .
Fig. 47: Sunroof Switch Electrical Connector
Courtesy of GENERAL MOTORS CORP.
2. Disconnect the electrical connector from the sunroof switch.
3. With a flat-bladed tool, carefully release the tabs that retain the sunroof switch to the
Tighten: 5 N.m (44 lb in)
2
Sunroof Window Stop (Qty: 2)
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Sunroof - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
