Chevrolet Silverado / GMC Sierra. Manual - part 2675
12. Connect the front park brake cable to the front to intermediate park brake cable connector.
13. Lower the vehicle.
14. Enable the park brake cable automatic adjuster. Refer to Parking Brake Cable Adjuster
Enabling.
15. Adjust the park brake. Refer to Park Brake Adjustment (Drum Brake) or Park Brake
Adjustment (Disc Brake).
PARKING BRAKE INDICATOR SWITCH REPLACEMENT
Removal Procedure
CAUTION: Refer to Battery Disconnect Caution .
2008 Chevrolet Silverado 1500
2008 BRAKES Park Brake - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 11: Park Brake Warning Lamp Switch Electrical Connector
Courtesy of GENERAL MOTORS CORP.
1. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection
and Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
Connection (w/Dual Batteries) .
2. Without disconnecting the electrical connectors, remove the left side instrument panel
electrical center/junction block and position aside. Refer to Instrument Panel Electrical
Center or Junction Block Replacement - Left Side .
3. Disconnect the park brake warning lamp switch electrical connector.
2008 Chevrolet Silverado 1500
2008 BRAKES Park Brake - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 12: Park Brake Warning Lamp Switch Mounting Bolt
Courtesy of GENERAL MOTORS CORP.
4. Remove the park brake warning lamp switch bolt.
5. Remove the park brake warning lamp switch.
2008 Chevrolet Silverado 1500
2008 BRAKES Park Brake - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Installation Procedure
Fig. 13: Park Brake Warning Lamp Switch Mounting Bolt
Courtesy of GENERAL MOTORS CORP.
1. Install the park brake warning lamp switch.
2008 Chevrolet Silverado 1500
2008 BRAKES Park Brake - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
