Chevrolet Silverado / GMC Sierra. Manual - part 2620
Fig. 97: Removing Retaining Bolt From 3rd And 4th Stop
Courtesy of GENERAL MOTORS CORP.
8. Using a punch and a hammer, remove the retaining bolt from the 3rd and 4th stop.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 98: Removing Retaining Bolt From 3rd And 4th Fork
Courtesy of GENERAL MOTORS CORP.
9. Using a punch and a hammer, remove the retaining bolt from the 3rd and 4th fork.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 99: Using A Punch To Turn 3rd And 4th Lever
Courtesy of GENERAL MOTORS CORP.
10. Using a punch, turn the 3rd and 4th lever to release it from the anchor bolt and remove it.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
