Chevrolet Silverado / GMC Sierra. Manual - part 2618
Fig. 89: 2nd Speed Synchronizer Ring
Courtesy of GENERAL MOTORS CORP.
24. Remove the 2nd speed synchronizer ring.
SHIFT SHAFT AND FORK ASSEMBLIES DISASSEMBLE
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 90: Removing Roll Pin From Yoke And Reverse Gearshift Lever
Courtesy of GENERAL MOTORS CORP.
1. Using a hammer and a punch, remove the roll pin from the yoke and the reverse gearshift
lever.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 91: Turning Reverse Gearshift Lever Usiing Punch
Courtesy of GENERAL MOTORS CORP.
2. Using a punch, turn the reverse gearshift lever to free it from the roll pin and remove.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
