Chevrolet Silverado / GMC Sierra. Manual - part 2619
Fig. 93: Remove 1st And 2nd Speed Stop Pin
Courtesy of GENERAL MOTORS CORP.
4. Remove the 1st and 2nd speed stop pin. Use care with the anchor bolt.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 94: Removing Retaining Bolt From Fork And 1st And 2nd Lever
Courtesy of GENERAL MOTORS CORP.
5. Using a punch and hammer, remove the retaining bolt from the fork and the 1st and 2nd
lever.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 95: Turning 1st And 2nd Lever Using Punch
Courtesy of GENERAL MOTORS CORP.
6. Using a punch, turn the 1st and 2nd lever to release it from the anchor bolt and remove it.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
