Fig. 46: Engine Mount-To-Frame Bracket Bolts (Left)
Courtesy of GENERAL MOTORS CORP.
10. Install the engine mount-to-frame bracket bolts.
Tighten: Tighten the engine mount-to-frame bracket bolts to 65 N.m (48 lb ft).
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
ENGINE MOUNT BRACKET REPLACEMENT - RIGHT SIDE
Removal Procedure
Fig. 47: Engine Mount Bracket (Right)
Courtesy of GENERAL MOTORS CORP.
1. Remove the engine mount. Refer to Engine Mount Replacement - Right Side.
2. Remove the engine mount bracket bolts.
3. Remove the engine mount bracket.
Installation Procedure
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
Fig. 48: Engine Mount Bracket (Right)
Courtesy of GENERAL MOTORS CORP.
1. Install the engine mount bracket.
2. Perform the following procedure prior to installing the engine mount bracket bolts:
Remove all traces of the original adhesive patch.
Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry.
Apply threadlocker GM P/N 12345382 (Canadian P/N 10953489) or equivalent to the
bolts.
NOTE:
Refer to Fastener Notice .
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
3. Install the engine mount bracket bolts.
Tighten: Tighten the engine mount bracket bolts to 75 N.m (55 lb ft).
4. Install the engine mount. Refer to Engine Mount Replacement - Right Side.
UPPER INTAKE MANIFOLD SIGHT SHIELD REPLACEMENT (6.0L (LQ4))
Removal Procedure
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
