ENGINE MOUNT BRACKET REPLACEMENT - LEFT SIDE Removal Procedure Fig. 39: Engine Mount Bracket (Left) 1. Remove the engine mount. Refer to Engine Mount Replacement - Left Side. 2. Remove the engine mount bracket bolts. 3. Remove the engine mount bracket. Installation Procedure
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
Fig. 40: Engine Mount Bracket (Left) 1. Install the engine mount bracket. 2. Perform the following procedure prior to installing the engine mount bracket bolts: Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply threadlocker GM P/N 12345382 (Canadian P/N 10953489) or equivalent to the
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
3. Install the engine mount bracket bolts. Tighten: Tighten the engine mount bracket bolts to 75 N.m (55 lb ft). 4. Install the engine mount. Refer to Engine Mount Replacement - Left Side. ENGINE MOUNT REPLACEMENT - RIGHT SIDE Removal Procedure NOTE: Refer to Fastener Notice .
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
Fig. 41: Engine Mount-To-Frame Bracket Bolts (Left) 1. Remove the engine mount-to-frame bracket bolts. 2. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle .
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
|
|
