FRONT FLOOR CONSOLE COMPARTMENT BEZEL REPLACEMENT Fig. 70: View Of Front Floor Console Compartment Bezel Assembly & Clips 3 1. Note location and routing of the instrument panel wiring harness prior to removal of the instrument panel carrier support assembly to ensure proper 2. Disconnect the wiring harness from the instrument panel carrier support assembly. 3. With the aid of an assistant, remove the instrument panel carrier support assembly from the vehicle. 4. If replacing the instrument panel carrier support assembly, transfer all necessary components. Callout Component Name 1 Front Floor Console Compartment Bezel Assembly 1. Disconnect the electrical connections.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Instrument Panel and Console Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
FRONT FLOOR CONSOLE COMPARTMENT DOOR LATCH REPLACEMENT (EXCEPT Fig. 71: View Of Front Floor Console Cover Latch Assembly & Components 2. If replacing the front floor console compartment bezel, transfer all necessary components. 2 Retainer Clips (Qty: 4) Callout Component Name 1 Front Floor Console Inner Cover Panel Screws (Qty: 8) Tighten: 2 N.m (18 lb in) NOTE: Refer to Fastener Notice . 2 Front Floor Console Inner Panel Front Floor Console Latch Inner Screws (Qty: 2)
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Instrument Panel and Console Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
FRONT FLOOR CONSOLE CUP HOLDER REPLACEMENT Fig. 72: View Of Front Floor Console Rear Cup Holder Assembly & Screws 3 Tighten: 2 N.m (18 lb in) 4 Front Floor Console Latch Outer Screws (Qty: 2) Tighten: 2 N.m (18 lb in) 5 Front Floor Console Cover Latch Assembly Callout Component Name 1 Front Floor Console Rear Cupholder Assembly Screws (Qty: 3) Tighten: 2 N.m (18 lb in) NOTE: Refer to Fastener Notice . 2 Front Floor Console Rear Cupholder Assembly
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Instrument Panel and Console Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
FRONT FLOOR CONSOLE SIDE TRIM PANEL REPLACEMENT - RIGHT SIDE (WITH RPO SLT) Fig. 73: View Of Console Side Trim Panel & Clips FRONT FLOOR CONSOLE SIDE TRIM PANEL REPLACEMENT - LEFT SIDE (WITH RPO SLT) Callout Component Name 1 Console Side Trim Panel 2 Retainer Clips (Qty: 2)
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Instrument Panel and Console Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
