ENDGATE EMBLEM/NAMEPLATE REPLACEMENT (GMC)

Callout

Component Name

1

Endgate Nameplate/Emblem (SLT)

Procedure

1. Use a J 25070 or equivalent to remove the old nameplate. Clean all the adhesive

residue from the endgate, wipe the surface dry with a clean lint-free towel prior to
installing new nameplate.

2. When removing protective liners from adhesive backed nameplates, be careful not to

touch the tape with hands and do not allow the tape to come in contact with dirt or
any foreign matter prior to adhesion.

3. Close the endgate prior to installing the new nameplate/emblem to the endgate.

4. Remove the protective liner from the back side of the adhesive tape.

5. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made.

NOTE:

Refer to Exterior Trim Emblem Removal Notice .

2

Endgate Nameplate/Emblem (SLE)

Procedure

1. Use a J 25070 or equivalent to remove the old nameplate/emblem. Clean all the

adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel
prior to installing new nameplate.

2. When removing protective liners from adhesive backed nameplates/emblems, be

careful not to touch the tape with hands and do not allow the tape to come in contact
with dirt or any foreign matter prior to adhesion.

3. Close the endgate prior to installing the new nameplate/emblem to the endgate.

4. Remove the protective liner from the back side of the adhesive tape.

5. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made.

NOTE:

Refer to Exterior Trim Emblem Removal Notice .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Exterior Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:26:40 PM

Page 16

© 2005 Mitchell Repair Information Company, LLC.

Fig. 14: View Of Endgate Emblem and Nameplate (GMC)
Courtesy of GENERAL MOTORS CORP.

Callout

Component Name

1

Endgate Nameplate/Emblem (Sierra)

Procedure

1. Use a J 25070 or equivalent to remove the old nameplate. Clean all the adhesive

residue from the endgate, wipe the surface dry with a clean lint-free towel prior to
installing new nameplate.

2. When removing protective liners from adhesive backed nameplates, be careful not to

touch the tape with hands and do not allow the tape to come in contact with dirt or
any foreign matter prior to adhesion.

3. Close the endgate prior to installing the new nameplate/emblem to the endgate.

4. Remove the protective liner from the back side of the adhesive tape.

5. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made.

NOTE:

Refer to Exterior Trim Emblem Removal Notice .

Endgate Nameplate/Emblem (GMC)



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Exterior Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:26:40 PM

Page 17

© 2005 Mitchell Repair Information Company, LLC.

ENDGATE EMBLEM/NAMEPLATE REPLACEMENT (CHEYENNE OR SILVERADO)

Fig. 15: View Of Endgate Emblem and Nameplate (Cheyenne or Silverado)
Courtesy of GENERAL MOTORS CORP.

2

Procedure

1. Use a J 25070 or equivalent to remove the old nameplate/emblem. Clean all the

adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel
prior to installing new nameplate.

2. When removing protective liners from adhesive backed nameplates/emblems, be

careful not to touch the tape with hands and do not allow the tape to come in contact
with dirt or any foreign matter prior to adhesion.

3. Close the endgate prior to installing the new nameplate/emblem to the endgate.

4. Remove the protective liner from the back side of the adhesive tape.

5. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made.

NOTE:

Refer to Exterior Trim Emblem Removal Notice .

Callout

Component Name

Endgate Nameplate/Emblem (Silverado)

NOTE:

Refer to Exterior Trim Emblem Removal Notice .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Exterior Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:26:40 PM

Page 18

© 2005 Mitchell Repair Information Company, LLC.

ENDGATE EMBLEM/NAMEPLATE REPLACEMENT (CHEYENNE LT LS)

1

Procedure

1. Use a J 25070 or equivalent to remove the old nameplate. Clean all the adhesive

residue from the endgate, wipe the surface dry with a clean lint-free towel prior to
installing new nameplate.

2. When removing protective liners from adhesive backed nameplates, be careful not to

touch the tape with hands and do not allow the tape to come in contact with dirt or
any foreign matter prior to adhesion.

3. Close the endgate prior to installing the new nameplate/emblem to the endgate.

4. Remove the protective liner from the back side of the adhesive tape.

5. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made.

2

Endgate Nameplate/Emblem (Cheyenne)

Procedure

1. Use a J 25070 or equivalent to remove the old nameplate/emblem. Clean all the

adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel
prior to installing new nameplate.

2. When removing protective liners from adhesive backed nameplates/emblems, be

careful not to touch the tape with hands and do not allow the tape to come in contact
with dirt or any foreign matter prior to adhesion.

3. Close the endgate prior to installing the new nameplate/emblem to the endgate.

4. Remove the protective liner from the back side of the adhesive tape.

5. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made.

NOTE:

Refer to Exterior Trim Emblem Removal Notice .
