FRONT SIDE DOOR EMBLEM/NAMEPLATE REPLACEMENT (GME)

Fig. 10: View Of Door Emblem and Nameplate (GME)
Courtesy of GENERAL MOTORS CORP.

1

remain 21°C (70°F) for one hour after assembly to allow adhesive to develop
sufficient bond strength.

2. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. Clean all the

adhesive residue from the door and wipe the surface dry with a clean lint-free towel
prior to installing new nameplate.

3. When removing protective liners from adhesive backed nameplates, be careful not to

touch the tape with hands and do not allow the tape to come in contact with dirt or
any foreign matter prior to adhesion.

4. Close the door prior to installing the new nameplate/emblem to the door.

5. Remove the protective liner from the back side of the adhesive tape.

6. Align the nameplate/emblem to the door and press to ensure full adhesion is made to

the door.

Callout

Component Name

Front Side Door Nameplate (GM)


Tip:

1. The part and surface should be 21°C (70°F) prior to installation. The vehicle should

NOTE:

Refer to Exterior Trim Emblem Removal Notice .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Exterior Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:26:40 PM

Page 12

© 2005 Mitchell Repair Information Company, LLC.

FRONT SIDE DOOR EMBLEM/NAMEPLATE REPLACEMENT (GMC ALLISON DURAMAX)

Fig. 11: View Of Door Emblem and Nameplate (GMC Allison Duramax)
Courtesy of GENERAL MOTORS CORP.

1

remain 21°C (70°F) for one hour after assembly to allow adhesive to develop
sufficient bond strength.

2. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. Clean all the

adhesive residue from the door and wipe the surface dry with a clean lint-free towel
prior to installing the new GM nameplate.

3. When removing protective liners from adhesive backed nameplates, be careful not to

touch the tape with hands and do not allow the tape to come in contact with dirt or
any foreign matter prior to adhesion.

4. Press the nameplate firmly to the front side door to ensure full adhesion is made to

the door.

Callout

Component Name

Front Side Door Nameplate/Emblem (Allison Duramax)

NOTE:

Refer to Exterior Trim Emblem Removal Notice .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Exterior Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:26:40 PM

Page 13

© 2005 Mitchell Repair Information Company, LLC.

ENDGATE EMBLEM/NAMEPLATE REPLACEMENT (Z71)

Fig. 12: View Of Endgate Emblem and Nameplate (Z71)
Courtesy of GENERAL MOTORS CORP.

1

Procedure

1. The part and surface should be 21°C (70°F) prior to installation. The vehicle should

remain 21°C (70°F) for one hour after assembly to allow adhesive to develop
sufficient bond strength.

2. Use a J 25070 Heat Gun or equivalent to remove the old emblem/nameplate. Clean

all the adhesive residue from the door and wipe the surface dry with a clean lint-free
towel prior to installing new emblem/nameplate.

3. When removing protective liners from adhesive backed emblem/nameplates, be

careful not to touch the tape with hands and do not allow the tape to come in contact
with dirt or any foreign matter prior to adhesion.

4. Close the door prior to installing the new emblem/nameplate to the door.

5. Remove the protective liner from the back side of the adhesive tape.

6. Align the emblem/nameplate to the door and press to ensure full adhesion is made to

the door.

Callout

Component Name



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Exterior Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &

Silverado



Microsoft



Friday, August 21, 2009 2:26:40 PM

Page 14

© 2005 Mitchell Repair Information Company, LLC.

ENDGATE EMBLEM/NAMEPLATE REPLACEMENT (GMC SLE SLT)

Fig. 13: View Of Endgate Emblem and Nameplate (GMC SLE SLT)
Courtesy of GENERAL MOTORS CORP.

1

Endgate Nameplate/Emblem (Z71)

Procedure

1. Use a J 25070 or equivalent to remove the old nameplate. Clean all the adhesive

residue from the endgate, wipe the surface dry with a clean lint-free towel prior to
installing new nameplate.

2. When removing protective liners from adhesive backed nameplates, be careful not to

touch the tape with hands and do not allow the tape to come in contact with dirt or
any foreign matter prior to adhesion.

3. Close the endgate prior to installing the new nameplate/emblem to the endgate.

4. Remove the protective liner from the back side of the adhesive tape.

5. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made.

NOTE:

Refer to Exterior Trim Emblem Removal Notice .
