Removal Procedure Fig. 386: View Of Oil Pan Cover, Bolts & Gasket 1. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle . 2. Remove the oil pan cover bolts (435), cover (434), and gasket (433). Discard the gasket. Installation Procedure
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 387: View Of Oil Pan Cover, Bolts & Gasket 1. Position a NEW oil pan cover gasket (433) and the cover (434) to the oil pan and install the bolts (435). Tighten: Tighten the bolts to 12 N.m (106 lb in). 2. Lower the vehicle. OIL PAN REPLACEMENT (2WD) Removal Procedure NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 388: View Of Oil Pan Skid Plate & Bolts 1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . 2. For 1500 series vehicles, remove the oil pan skid plate bolts and skid plate, if equipped.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 389: View Of Oil Pan Skid Plate & Bolts 3. For 2500 series vehicles, loosen the 2 rear oil pan skid plate bolts, remove the 2 front oil pan skid plate bolts and skid plate, if equipped. 4. Unbolt the steering rack and hang downward.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
