Tighten:
1. Tighten the oil pan-to-rear oil seal housing bolts to 12 N.m (106 lb in).
2. Tighten the rear oil seal housing bolts to 30 N.m (22 lb ft).
8. Remove the J 41476 . See Special Tools .
9. Install a NEW crankshaft rear oil seal. Refer to Crankshaft Rear Oil Seal Replacement.
10. Remove the automatic transmission flexplate, refer to Automatic Transmission Flex Plate
Replacement .
OIL FILTER ADAPTER REPLACEMENT
Removal Procedure
Fig. 378: View Of Oil Pan Skid Plate & Bolts
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Courtesy of GENERAL MOTORS CORP.
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
2. For 1500 series vehicles, remove the oil pan skid plate bolts and skid plate, if equipped.
Fig. 379: View Of Oil Pan Skid Plate & Bolts
Courtesy of GENERAL MOTORS CORP.
3. For 2500 series vehicles, loosen the 2 rear oil pan skid plate bolts, remove the 2 front oil
pan skid plate bolts and skid plate, if equipped.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 380: View Of Engine Oil Filter
Courtesy of GENERAL MOTORS CORP.
4. Place a suitable drain pan under the oil filter.
5. Remove the oil filter (437).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 381: View Of Oil Filter Fitting
Courtesy of GENERAL MOTORS CORP.
6. Remove the oil filter adapter (438).
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
