Chevrolet Silverado / GMC Sierra. Manual - part 1783
Fig. 303: View Of Generator & Bolts
Courtesy of GENERAL MOTORS CORP.
8. Remove the generator bolts.
9. Remove the generator.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 304: View Of Generator & Bolts
Courtesy of GENERAL MOTORS CORP.
1. Install the generator.
2. Install the generator bolts.
Tighten: Tighten the bolts to 55 N.m (41 lb ft).
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 305: View Of Battery Jumper Cable Terminal, Nut & Bolt
Courtesy of GENERAL MOTORS CORP.
3. Install the generator battery jumper cable terminal (1) to the generator stud.
4. Install the generator battery jumper cable nut (2) to the generator.
Tighten: Tighten the nut to 9 N.m (80 lb in).
5. Position the generator battery jumper cable boot (3).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 306: View Of Generator & Related Connectors
Courtesy of GENERAL MOTORS CORP.
6. Connect the engine harness electrical connector (3) to the generator.
7. Install the accessory drive belt. Refer to Drive Belt Replacement - Accessory .
8. Install the intake manifold sight shield. Refer to Upper Intake Manifold Sight Shield
Replacement .
9. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and
Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
Connection (w/Dual Batteries).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
