Tighten: Tighten the nut to 9 N.m (80 lb in). Fig. 288: View Of Indicator Tube Bracket & Bolts 8. Install the oil level indicator tube bracket (2). 9. Install the oil level indicator tube bracket bolts (1). Tighten: Tighten the bolts to 21 N.m (15 lb ft). 10. Install the oil level indicator tube bolt (3).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Tighten: Tighten the bolts to 21 N.m (15 lb ft). 11. Install the engine wiring harness clip to the oil level indicator tube bracket (2). 12. Install the drive belt tensioner. Refer to Drive Belt Tensioner Replacement . 13. Install the generator. Refer to Generator Replacement (4.3L) or Generator Replacement (4.8L, 5.3L, 6.0L, and 6.2L) or Generator Replacement (6.6L). 14. Install the intake air heater. Refer to Intake Air Heater Replacement . 15. Install the upper fan shroud. Refer to Engine Coolant Fan Upper Shroud Replacement (Mechanical) or Engine Coolant Fan Upper Shroud Replacement (Automatic 16. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection (w/Single Battery) or Battery Negative Cable Disconnection and AUXILIARY GENERATOR BRACKET REPLACEMENT (6.6L) Removal Procedure
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 289: View Of Auxiliary Generator Bracket & Bolt 1. Remove the auxiliary generator. Refer to Auxiliary Generator Replacement (6.6L). 2. Remove the auxiliary generator bracket bolt (2). 3. Remove the auxiliary generator bracket (1). Installation Procedure
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 290: View Of Auxiliary Generator Bracket & Bolt 1. Position the auxiliary generator bracket (2) to the air conditioning (A/C) bracket. 2. Install the auxiliary generator bracket bolt (1). Tighten: Tighten the bolt to 50 N.m (37 lb ft). 3. Install the auxiliary generator. Refer to Auxiliary Generator Replacement (6.6L). GENERATOR REPLACEMENT (4.3L) NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
