Chevrolet Silverado / GMC Sierra. Manual - part 1753
Fig. 189: View Of Starter Solenoid Cable Clip & Bolt
Courtesy of GENERAL MOTORS CORP.
12. Position the starter solenoid cable clip to the frame and install the starter solenoid cable clip
bolt (2).
13. Install the starter solenoid cable clip (1) to the wheelhouse panel.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 190: View Of Oil Pan Skid Plate & Bolts
Courtesy of GENERAL MOTORS CORP.
14. Install the oil pan skid plate and tighten the rear 2 bolts and install and tighten the front 2
bolts.
Tighten: Tighten the bolts to 28 N.m (21 lb ft).
15. Lower the vehicle.
16. Install the air cleaner outlet duct. Refer to Air Cleaner Resonator Outlet Duct
Replacement .
17. Connect the auxiliary battery negative cable. Refer to Battery Negative Cable
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Disconnection and Connection (w/Single Battery) or Battery Negative Cable
Disconnection and Connection (w/Auxiliary Battery) or Battery Negative Cable
Disconnection and Connection (w/Dual Batteries).
BATTERY REPLACEMENT
Removal Procedure
CAUTION: Refer to Battery Disconnect Caution.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 191: View Of Battery Cable Components
Courtesy of GENERAL MOTORS CORP.
1. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection
and Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
Connection (w/Dual Batteries).
2. Open the starter solenoid cable cover at the positive battery terminal.
3. Loosen the starter solenoid cable nut (5).
4. Remove the starter solenoid cable from the positive battery terminal.
5. Reposition the starter solenoid cable out of the way.
Fig. 192: View Of Front Fender Rear Upper Brace & Bolts
Courtesy of GENERAL MOTORS CORP.
6. Remove the front fender rear upper brace bolts and brace.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
