Chevrolet Silverado / GMC Sierra. Manual - part 1747
Fig. 165: View Of Battery Components
Courtesy of GENERAL MOTORS CORP.
2. Install the starter solenoid cable (5) to the battery positive post.
3. Tighten the starter solenoid cable nut (2).
Tighten: Tighten the nut to 5 N.m (44 lb in).
4. Close the starter solenoid cable positive battery post cover (1).
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 166: View Of Negative Battery Cable & Components
Courtesy of GENERAL MOTORS CORP.
5. Install the starter solenoid cable to the battery positive post.
6. Tighten the starter solenoid cable nut (1).
Tighten: Tighten the nut to 7.5 N.m (66 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
7. Close the starter solenoid cable positive battery post cover.
8. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle .
Fig. 167: View Of Starter Solenoid Cable Channel Bolts
Courtesy of GENERAL MOTORS CORP.
9. Position the starter solenoid cable to the oil pan and install the starter solenoid cable
channel bolts (1).
Tighten: Tighten the bolts to 12 N.m (106 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 168: View Of Starter Solenoid Cable Terminal, Bracket & Bolts
Courtesy of GENERAL MOTORS CORP.
10. Reposition the starter solenoid cable bracket (1) and install the engine wiring harness to the
clips on the rear of the bracket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
