Chevrolet Silverado / GMC Sierra. Manual - part 1746
Fig. 161: View Of Starter Solenoid Cable Terminal, Bracket & Bolts
Courtesy of GENERAL MOTORS CORP.
27. Reposition the starter solenoid cable bracket (1) and remove the engine wiring harness from
the rear clips on the bracket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 162: View Of Starter Solenoid Cable Channel Bolts
Courtesy of GENERAL MOTORS CORP.
28. Remove the starter solenoid cable channel bolts (1).
29. Lower the vehicle.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 163: View Of Starter Solenoid Cable
Courtesy of GENERAL MOTORS CORP.
30. Remove the starter solenoid cable from the vehicle.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
