Fig. 29: View Of Hood & Bolts
Courtesy of GENERAL MOTORS CORP.

Callout

Component Name

Preliminary Procedure

1. Disconnect the hood strut. Refer to Hood Strut Replacement.

2. Remove the air inlet panel end panels. Refer to Air Inlet Grille Panel Replacement .

CAUTION:

When a hood hold open device is being removed or installed, provide alternate support to avoid the
possibility of damage to the vehicle or personal injury.

Hood Link Upper Bolt (Qty: 2)

NOTE:

Refer to Fastener Notice .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Bolted Exterior Body Panels and Closures - Cab & Chassis Sierra, Cab & Chassis

Silverado, Sierra & Silverado



Microsoft



Friday, August 21, 2009 2:23:22 PM

Page 35

© 2005 Mitchell Repair Information Company, LLC.

HOOD INSULATOR REPLACEMENT

Fig. 30: View Of Hood Insulator & Retainers
Courtesy of GENERAL MOTORS CORP.

1

Tighten: 25 N.m (18 lb ft)


Tip: Disconnect any electrical connectors before removing.

2

Hood Hinge Pivot Bolt (Qty: 2)

Tighten: 25 N.m (18 lb ft)

3

Hood
Tip:



Disconnect any electrical connectors before removing.



Transfer any parts as needed.



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Bolted Exterior Body Panels and Closures - Cab & Chassis Sierra, Cab & Chassis

Silverado, Sierra & Silverado



Microsoft



Friday, August 21, 2009 2:23:22 PM

Page 36

© 2005 Mitchell Repair Information Company, LLC.

HOOD PRIMARY AND SECONDARY LATCH REPLACEMENT

Fig. 31: View Of Hood Latch & Bolts
Courtesy of GENERAL MOTORS CORP.

Callout

Component Name

1

Hood Insulator Plastic Retainer (Qty: 8)

2

Hood Insulator

Callout

Component Name

Preliminary Procedure:
Remove the radiator air upper baffle/deflector. Refer to Radiator Air Upper Baffle and Deflector
Replacement

1

Hood Latch Bolts (Qty: 3)


Tip: Use a grease pencil to mark the location of the hood latch before removing the bolts.

Tighten: 9 N.m (80 lb in)

NOTE:

Refer to Fastener Notice .



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Bolted Exterior Body Panels and Closures - Cab & Chassis Sierra, Cab & Chassis

Silverado, Sierra & Silverado



Microsoft



Friday, August 21, 2009 2:23:22 PM

Page 37

© 2005 Mitchell Repair Information Company, LLC.

HOOD LINK REPLACEMENT

Fig. 32: View Of Hood Hinge Spring & Bolt
Courtesy of GENERAL MOTORS CORP.

2

Hood Latch
Tip: Disconnect any electrical connectors.

Callout

Component Name

Preliminary Procedures

1. Prop and support the hood.

2. Remove the hood link upper bolt. Refer to Hood Replacement

CAUTION:

When a hood hold open device is being removed or installed, provide alternate support to avoid the
possibility of damage to the vehicle or personal injury.

Hood Link Lower Bolt



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Bolted Exterior Body Panels and Closures - Cab & Chassis Sierra, Cab & Chassis

Silverado, Sierra & Silverado



Microsoft



Friday, August 21, 2009 2:23:22 PM

Page 38

© 2005 Mitchell Repair Information Company, LLC.
