Fig. 464: View Of Manual Valve 1. Remove the manual valve (340). CAUTION: Refer to Valve Springs Can Be Tightly Compressed Caution .
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 465: Exploded View Of Forward Abuse & Low Overrun Components 2. Remove the forward accumulator cover bolts (364) and the forward accumulator cover (363). 3. Remove the forward accumulator spring (356), forward accumulator piston (354), and the forward accumulator pin (355). 4. Remove the low overrun valve spring (362) and the low overrun valve (361). 5. Remove the coiled spring pin (360) and the bore plug (359). 6. Remove the forward abuse valve spring (358) and the forward abuse valve (357).
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 466: View Of 1-2 Shift Solenoid & Retainer 7. Remove the solenoid retainer (395) and the 1-2 shift solenoid (367A). 8. Remove the 1-2 shift valve (366) and the 1-2 shift valve spring (365).
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 467: View Of 2-3 Shift Solenoid & 2-3 Shift Valve 9. Remove the solenoid retainer (395) and the 2-3 shift solenoid (367B). 10. Remove the 2-3 shuttle valve (369) and the 2-3 shift valve (368).
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
