Chevrolet Silverado / GMC Sierra. Manual - part 1084
Fig. 223: View Of Fuel Line Bracket Bolt
Courtesy of GENERAL MOTORS CORP.
9. Install the bolt that secures the fuel line bracket to the left side of the transmission.
Tighten: Tighten the bolt to 10 N.m (89 lb in).
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 224: View Of Transmission Harness 20-Way Connector & VSS Electrical
Connector
Courtesy of GENERAL MOTORS CORP.
10. Connect the main electrical connector (1) and vehicle speed sensor (2) to the transmission.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 225: View Of PNP Switch Electrical Connector
Courtesy of GENERAL MOTORS CORP.
11. Connect park/neutral position switch connector (2).
12. Attach the wire harness (1) to the bracket.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 226: View Of Transmission Vent Hose
Courtesy of GENERAL MOTORS CORP.
13. Connect the transmission vent hose.
14. Install the range selector cable to the transmission. Refer to Range Selector Lever Cable
Replacement.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
